Fall Arrest Blocks with Recovery Winch
Rebel 15m Fall Arrest Retrieve Block
The Rebel 15m Fall Arrest Retrieve Block adds versatility and convenience to the trusted Rebel self-retracting lifelines. These models incorporate fall arrest and a built-in emergency fall arrest retrieval system. The retrieval facility gives added peace of mind that, should a fall occur, the operative rescue plan has already been catered for.
This unit can be provided with an option of a stainless steel cable or a galvanised cable.
| Weekly hire rate excluding VAT | |
| Rebel 15m Fall Arrest Retrieve Block with Bracket | £56.00 |
| Rebel 15m Fall Arrest Retrieve Block with Scaffold Karabiner | £56.00 |
| Sales price excluding VAT | |
| Rebel 15m Fall Arrest Retrieve Block with Galvanised Rope | £801.00 |
| Rebel 15m Fall Arrest Retrieve Block with Stainless Steel Rope | £865.40 |
| Rebel 15m Fall Arrest Retrieve Block Bracket for P-T7 | £94.40 |
| Rebel 15m Fall Arrest Retrieve Block Bracket for AM100 | £252.20 |
| Service price excluding parts and VAT | |
| Rebel Fall Arrest Retrieve Block | £65.00 |
| Physical Weight: | 11.9kg |
| Dimensions: | 14cm x 28cm x 61cm |
| Safe Working Load: | 140kg for operator and tools |
| Standards: | CE EN 360: 2002 EN 1496: 2006 class B |
RGA4 Fall Arrest Block with Recovery Winch
The RGA4 is a 15 metre fall arrest block with recovery winch is constructed from rugged aluminium cases for durability. The unit has a fall indicator tag for added peace of mind. All fall arrest recovery blocks are designed primarily as a fall arrest unit, with a single use retrieval facility.
The retrieval facility gives added peace of mind that, should a fall occur, the operative rescue plan has already been catered for.
The unit has been accredited to EN 360:2002 and has a maximum user weight of 140kg.
| Weekly hire rate excluding VAT | |
| RGA4 Fall Arrest Block with Recovery Winch and Bracket | £56.00 |
| RGA4 Fall Arrest Block with Recovery Winch and Scaffold Karabiner | £56.00 |
| Sales price excluding VAT | |
| RGA4 Fall Arrest Block with Recovery Winch | £1,092.50 |
| RGA4B Bracket for RGA4 | £186.30 |
| Scaffold Karabiner to fit RGA4 | £45.00 |
| Service price excluding parts and VAT | |
| RGA4 Fall Arrest Block with Recovery Winch | £65.00 |
| Physical Weight: | 11.4kg |
| Maximum Force: | <6kN |
| Maximum User Weight: | 140kg |
| Standards: | EN 360:2002 |
RGA4H/Edge Fall Arrest Block with Recovery Winch
The RGA4H is a 15 metre fall arrest block with a shock pack which means it can be used whilst working over the edge. The block has a steadying handle fitted with an up/down winch mechanism. The unit has a fall indicator tag for added peace of mind.
The unit is constructed with durable cast alloy casings and comes with a 5mm galvanised wire cable and double action high tensile steel swivel karabiner. It has a maximum user weight of 140kg.
All fall arrest recovery blocks are designed primarily as a fall arrest unit, with a single use recovery facility. The recovery facility gives added peace of mind that, should a fall occur, the operative rescue plan has already been catered for as the operative can be winched up or down to safety in the event of an emergency.
The unit has been accredited to EN 360:2002, EN 1496:2017 B and VG11.060.
| Weekly hire rate excluding VAT | |
| RGA4H/Edge Fall Arrest Block with Recovery Winch and Bracket | £56.00 |
| RGA4H/Edge Fall Arrest Block with Recovery Winch and Scaffold Karabiner | £56.00 |
| Sales price excluding VAT | |
| RGA4H/Edge Fall Arrest Block with Recovery Winch | £1,092.50 |
| RGA4B Bracket for RGA4H/Edge | £186.30 |
| Scaffold Karabiner to fit RGA4H/Edge | £45.00 |
| Service price excluding parts and VAT | |
| RGA4H/Edge Fall Arrest Block with Recovery Winch | £65.00 |
| Physical Weight: | 11.2kg |
| Maximum Force: | <6kN |
| Maximum User Weight: | 140kg |
| Standards: | EN 360:2002 EN 1496:2017 B VG11.060 |
Kratos Fall Arrest Retrieve Blocks
The Kratos fall arrest retrieve blocks have a polymer casing, galvanised steel wire rope and have a built in indicator hook and carrying handle. The units conform to EN360 for fall arrest and EN1496 for emergency recovery with a rated worker maximum load of 140kg.
The block is simple to use providing fall protection up to a 40 degree angle from centre. If the worker takes a fall the emergency recovery handle can be engaged to recover the worker. This then takes care of regulation 5 as your emergency rescue plan.
A fall arrest retrieve block can only be used as a secondary device as it is not designed for full man riding other than for an emergency rescue.
| Weekly hire rate excluding VAT | |
| FA 20 401 30 Retractable Fall Arrest Retrieve Block 30m Wire Rope | £65.00 |
You may need a special karabiner to install this unit
| Sales price excluding VAT | |
| FA 20 401 20 Retractable Fall Arrest Retrieve Block 20m Wire Rope | £1,074.50 |
| FA 20 401 30 Retractable Fall Arrest Retrieve Block 30m Wire Rope | £1,425.50 |
| Service price excluding parts and VAT | |
| All Kratos Fall Arrest Retrieve Blocks | £65.00 |
| Physical Weight: | FA20 401 20: 9.2kg FA20 401 30: 14.8kg |
| Dimensions: | FA20 401 20: 304mm x 279mm x 96mm FA20 401 30: 425mm x 278mm x 109mm |
| Breaking Strength: | >12kN |
| Safe Working Load: | Approved for a user with a maximum weight of 140kg in vertical use |
| Standards: | EN360: 2002 EN1496: 2017 ATEX Directive 2014/34/EU |
| ATEX Marking: | Ex 11 2G Ex h 11C T6 Gb |
Self-Retracting Sealed-Blok with Rescue Winch
The Sala Sealed-Blok series are the ultimate in durability and design. Rugged and made to last, the spring and bearing housing is sealed to a rating of IP 67 which means that the unit can be submerged to 1 metre for 30 minutes. With the addition of stainless steel wire ropes and the huge range in lengths these blocks are ideal for offshore and harsher environments.
These blocks are built so that they follow the definition of the law. That is that the block should always be used in fall arrest mode as a safety back up to the personnel descending using a ladder or step irons, or as a secondary device.
Only if a fall takes place should the recovery handle be used, the unit should then be serviced by an authorised service house.
You may require brackets to fit these units to tripods or davits and please contact us for assistance.
| Weekly hire rate excluding VAT | |
| Self-Retracting Sealed-Blok 15 metre Stainless Steel Wire Rope with Rescue Winch | £56.00 |
| Self-Retracting Sealed-Blok 25 metre Stainless Steel Wire Rope with Rescue Winch | £110.00 |
| Self-Retracting Sealed-Blok 40 metre Stainless Steel Wire Rope with Rescue Winch | £195.00 |
| Sales price excluding VAT | |
| Self-Retracting Sealed-Blok 9 metre Stainless Steel Wire Rope with Rescue Winch | £2,255.45 |
| Self-Retracting Sealed-Blok 15 metre Stainless Steel Wire Rope with Rescue Winch | £2,768.10 |
| Self-Retracting Sealed-Blok 25 metre Stainless Steel Wire Rope with Rescue Winch | £3,036.65 |
| Self-Retracting Sealed-Blok 40 metre Stainless Steel Wire Rope with Rescue Winch | £3,608.70 |
| Service price excluding parts and VAT | |
| All Self Retracting Sealed-Bloks with Retrieval Winch | £65.00 |
Blocfor ESD R Fall Arrester with Rescue Handle
The Blocfor ESD R Fall Arrester with Rescue Handle is suitable for use on terrace roofs and complies with CNB/P/11.062.
The unit can be used vertically or with a standard deviation of 20° in relation to vertical and also for horizontal use without the use of a lanyard between the end of the strap and the harness. The unit complies with EN 360, EN 1496B and CNB/P/11.060 standards for use on edges with a minimal 0.5 mm curve radius.
The Blocfor ESD R includes the Energy System Dissipater (ESD) technology that enables the unit to arrest a fall even when the webbing is fully unwound and ensures there is an impact force of less than 6 kN to the user in the event of a fall.
The Blocfor ESD R has a ABS fibre reinforced polyaminde housing that is resistant to shocks and aging. It has a standard M47 swivel connector at the end of the shock absorber and a 25mm anchorage on the unit to accommodate large-diameter connectors. They are available in 2 lengths of 20m and 30m and have a total user capacity of 150kgs
| Sales price excluding VAT | |
| Blocfor 20 ESD R Fall Arrester with Rescue Winch - 20m Galvanised Cable | £1,472.00 |
| Blocfor 30 ESD R Fall Arrester with Rescue Winch - 30m Galvanised Cable | £1,850.00 |
| Service price excluding parts and VAT | |
| Blocfor 30 ESD R Fall Arrester with Rescue Winch | £65.00 |
| Physical Weight: | Blocfor 20 ESD R: 9.34kg Blocfor 30 ESD R: 16kg |
| Dimensions: | Blocfor 20 ESD R: 930mm x 275mm x 100mm Blocfor 30 ESD R: 930mm x 320mm x 130mm |
| Safe Working Load: | Total user weight of 150kg |
| Standards: | EN360 EN1496 Class B VG11 CNB/P/11.060 technical data sheet "use on terrace roof" CNB/P/11.062 "Fall arrest with a capacity of more than 100 kg |
Saver Fall Arrester with Integrated Emergency Rescue Mechanism
The Saver is a retractable fall arrester with an integrated emergency rescue mechanism for raising or lowering personnel to safety following a fall
The recovery handle has a shock absorbing brake mechanism and an anti-run brake so that if the winding handle is released during lifting the winch automatically locks until the handle is rotated by the operator. It has a stopping distance of 0.6m to 1m and a retrieval speed of approximately 3m per minute. The karabiner has an incorporated fall indicator.
The unit can be mounted vertically overhead with up to a 30° angle from centre, with a diverter pulley, or horizontally providing the rope does not pass over sharp or abrasive edges, masonry or steelworks or other items that may catch, trap or shear the wire rope.
The Saver Fall Arrester has a maximum weight limit of 141kg and is available in 4 rope lengths of 10m, 14m, 20m and 34m.
The Saver is also available with a high performance HMPE fibre line which is beneficial in environments with electrocution risks. This low stretch line is up to 70% stronger that the current steel wire with less than half the density which reduces the overall weight of the unit by up to 2.5kg.
The unit is certified to EN 360:2022 and EN 1496:2006 Class B.
| Sales price excluding VAT | |
| Saver 10m Stainless Steel Rope & Stainless Steel Karabiner | £1,136.00 |
| Saver 14m Galvanised Rope & Zinc Plated Steel Snap Hook | £913.00 |
| Saver 14m HMPE Fibre Line & Zinc Plated Steel Snap Hook | £1,200.00 |
| Saver 20m Galvanised Rope & Zinc Plated Steel Snap Hook | £1,106.00 |
| Saver 20m Stainless Steel Rope & Stainless Steel Snap Hook | £1,270.00 |
| Saver 34m Galvanised Rope & Zinc Plated Steel Snap Hook | £1,453.00 |
| Saver 34m Stainless Steel Rope & Stainless Steel Karabiner | £1,704.00 |
| Saver to G.Tripod Upper Mounting Bracket | £112.00 |
| Saver to G.Tripod Lower Mounting Bracket | £137.00 |
| Saver 14m to G.Tripod One-Piece Mounting Bracket | £194.00 |
| Saver 20m to G.Tripod One-Piece Mounting Bracket | £227.00 |
| Saver 34m to G.Tripod One-Piece Mounting Bracket | £242.00 |
| Service price excluding parts and VAT | |
| Saver Fall Arrest Block with Rescue Winch | £65.00 |
| Description | Weight: (approx.) | MWL: |
| Saver 10m Stainless Steel Rope & Stainless Steel Karabiner | 12.5kg | 141kg |
| Saver 14m Galvanised Rope & Zinc Plated Steel Snap Hook | 12.5kg | 141kg |
| Saver 14m HMPE Fibre Line & Zinc Plated Steel Snap Hook | 10.0kg | 141kg |
| Saver 20m Galvanised Rope & Zinc Plated Steel Snap Hook | 17.0kg | 141kg |
| Saver 20m Stainless Steel Rope & Stainless Steel Snap Hook | 17.0kg | 141kg |
| Saver 34m Galvanised Rope & Zinc Plated Steel Snap Hook | 23.0kg | 141kg |
| Saver 34m Stainless Steel Rope & Stainless Steel Snap Hook | 23.0kg | 141kg |
